Exterior Length: 21’11”

Exterior Height (including A/C): 10’4″

Exterior Width:  7’0″

Interior Height: 6’4″

GVWR (lbs.): 5,000

Dry Weight (lbs.): 3,360

Dry Hitch Weight (lbs.): 382

Axles (lbs.): 2 @ 3,000

Tire Size:  235/75R15

Fresh Water (Tank only)(gal.):  31

Black Tank Capacity (gal.): 25

Gray Tank Capacity (gal.):  25

LP Capacity (lbs.):  40

Awning Length:  15′

Furnace (BTU): 18,000

STANDARD FEATURES

NXG Engineered Chassis • Exterior Fiberglass Sidewalls w/ Azdel • 13.5 BTU A/C • Convection Microwave • 10.3 cu. ft. 12V refrigerator (N/A 1700BH) • 6 Gallon Gas/Electric/DSI Water Heater • Aluminum Wheel Assemblies • Power Awning w/ LED Lighting • Roof Mount Solar Charger Prep • Power Tongue Jack • Recessed 2 Burner Cook Top w/ Glass Cover (1700BH Only) • Recessed Three Burner Cook Top w/ Back-lit Knobs & Glass Cover • 15” Offroad Tire/Axle Lift • Torflex Dexter Axle(s) • LED Exterior Lighting • Heated & Enclosed Holding Tanks • Radiant Foil Insulation • One-Piece TPO Roof Membrane • TPO front cap • AV System AM/FM/CD/DVD/USB/ Bluetooth • USB Charge Ports • TV Antenna • Exterior Speakers • LED TV • Backup Camera Prep • Wifi Prep • Wireless Cell Phone Charger • Exterior Ladder • (1) 190-watt solar panel w/ 30Amp charge control monitor & side mount solar prep* • 12v holding tank pad heaters w/ interior switch* • Power stabilizing jacks* • 2” accessory hitch receiver • 7-way plug holder • Triple solid entry step (1708FB, 1808FBS only) • Exterior patio side mounting bracket prep • TPMS prep • Camp side spray port
