Winnebago Ekko
The Winnebago® EKKO™ combines the efficiency of a camper van, the added capacity of a Class C coach, and the enhanced capability of AWD to create not just a new model, but an entirely new type of RV. The all-new AWD EKKO™ Sprinter expands the EKKO lineup, complementing the trailblazing EKKO Transit with enhanced off-road capability, living and storage space, and a new multifunctional living area.
Have Any Questions
Image Gallery
Ekko 22A Specifications
Weights and Measures
| 22A | |
|---|---|
| Exterior Length | 23’2″ |
| Exterior Height | 10’6″ |
| Exterior Width | 7’2.5″ |
| Exterior Storage (cu. ft.) | 65.3* |
| Awning Length | 13′ |
| Interior Height | 6’8″ |
| Interior Width | 6’9″ |
| Freshwater Tank Capacity (gal.) | 50 |
| Water Heater Capacity (gal.) | Continuous |
| Holding Tank Capacity — Black (gal.) | NA |
| Holding Tank Capacity — Gray (gal.) | 51 |
| LP Capacity (lbs.) | 40 |
| Fuel Capacity (gal.) | 31 |
| GCWR (lbs.) | 15,000 |
| GVWR (lbs.) | 11,000 |
| GAWR – Front (lbs.) | 4,630 |
| GAWR – Rear (lbs.) | 7,275 |
| Wheelbase | 156″ |
| Cassette Toilet Capacity (gal.) | 5 |
| Sleeps | 4 |
Chassis
-
Ford® AWD Transit Chassis
-
3.5L EcoBoost® V6 gas engine, 10-speed automatic Selectshift® transmission with overdrive
-
4-wheel anti-lock disc brakes
-
High-intensity discharge (HID) headlamps
-
Trailer hitch6 5,000-lb. drawbar/500-lb. maximum vertical tongue weight w/7-pin connector
-
Stylized performance wheels
-
Spare tire
Cab Conveniences
-
Radio/Rearview monitor system 8″ colored multi-function touchscreen with SYNC®3, navigation, AM/FM stereo with HD/SiriusXM® capability,
-
Bluetooth®, dual USB ports and integrated rear camera display
-
FordPass™ Connect
-
Cab seats armrest, fixed lumbar support, headrest, recline, slide and swivel
-
Airbags driver, passenger
-
3-point seat belts
-
2 cab seat lounge cushions
-
Power door lock w/remote control
-
Power windows
-
Power mirrors w/defrost and turn signals
-
Power assist steering w/tilt wheel
-
Adaptive cruise control
-
Lane-keeping assist
-
Pre-collision assist w/Automatic Emergency Braking (AEB)
-
Driver alert
-
Automatic rain-sensing wipers
-
Wiper activated headlamps
-
Auto headlamps w/high beam control
-
Blind spot monitoring
-
Tire pressure monitoring system
-
Sunvisors
-
Cab mat
-
Front wraparound curtain
-
Thermal cab divider wall panel
Interior
-
LED ceiling lights
-
Tinted dual-pane euro acrylic windows w/cassette shades
-
Dinette seating w/3-point seat belts
-
Pull-up/fold down table
-
Color touchscreen systems monitor panel
-
Vinyl flooring throughout
-
Satellite system ready
-
Amplified digital HDTV antenna
-
Roof wiring access port
-
Assist bar
-
RAM® Tough-Track™ Mount (dinette overhead)
-
110V, 12V, USB charging ports
-
Deluxe powered ventilator fan w/remote
- Overhead accent lighting
Optional Equipment:
- Entertainment system smart Blu-ray disc player, Bluetooth® soundbar and 24″ HDTV
Galley
- Galley drawer w/counter extension base (induction cooktop storage)
- Laminate countertops
- Microwave/convection oven w/touch controls
- Portable single burner induction range top
- 5.3 cu. ft. single door 12V refrigerator/freezer
- Stainless steel sink w/sink cover and single control faucet
- Water pump switch
Bath
- Medicine cabinet
- Mirror
- Oxygenics® shower head
- Dry/wet bath w/pivoting wall
- Robe hooks Shower 24″ x 30″ w/wall surround
- Shower curtain
- Molded round sink with single control faucet
- Tissue holder
- Swiveling cassette toilet
- Water pump switch
Bedroom
- 32″ x 80″ Twin beds w/WinnSleep® System
- Flex bed kit
- Wardrobe/drawer storage below beds
- Metal clothes rod
- Room divider curtain
- Reading lights
- 110V, 12V, USB charging ports
Exterior
- Heated gear garage w/L-track cargo tie down system, removable floor liner, 110V/12V charging ports and LED lighting
- Mud flaps
- Powered patio awning w/LED lighting and Bluetooth® control
- Ladder (N/A w/pop-top)
- Aluminum cab steps w/logoed tread and pet loop attachment
- LED Porch light w/interior switch
Optional Equipment:
- Pop-top sleeping area w/FROLI® sleep system and 110V, USB charging ports (N/A w/luggage rack, ladder)
- Batwing awning
- Luggage rack (N/A w/pop-top)
- Option to remove: Powered patio awning w/LED lighting and Bluetooth® control
- Option to remove: Exterior graphics
Heating & Cooling
- 13,500 BTU air conditioner
- Truma® VarioHeat™ comfort
Electrical System
- Auxiliary start circuit
- Automatic dual-battery charge control
- Coach battery disconnect system
- Dedicated second alternator to charge coach batteries
- Exterior AC duplex receptacle
- Exterior TV jack
- Cummins Onan® QG 2,500-watt LP generator
- 30-amp. power cord
- (2) 215-watt and (1) 100-watt solar panel/battery charger
- 220-watt flexible surface solar panel/battery charger (w/pop-top)
- 2,000-watt pure sine wave inverter/80-amp charger
- 320-amp-hour Lithionics® lithium ion battery w/Bluetooth control package and battery pack heating system
Optional Equipment:
- Option to delete: Cummins Onan® QG 2,500-watt LP generator
- (1) 630-amp-hour Lithionics® lithium ion battery (generator delete mandatory with this option)
Plumbing
- Insulated water service center houses water center control panel, hooks, cable tv input, freshwater drain and portable satellite dish hook-up
- Truma AquaGo® tankless comfort plus water heater w/recirculation pump
- On-demand water pump
- Cold water purification system (galley only)
- Heated holding tank compartment
- 10′ sewer hose
- Shower drain pump
- LPG accessory connection (patio area)
- (2) removable 20lb. LP cylinder tanks
Safety
- LPG leak, smoke and carbon monoxide detectors
- Fire extinguisher
- Ground fault interrupter
- (1) Upper child seat tether anchor
- High-mount brake lamps
- Fog lamps
Warranty
-
12-month/15,000-limited warranty
-
36-month/36,000-mile limited warranty
-
10-year limited parts-and-labor warranty on roof skin
Specifications are subject to change without notification.
Ekko 23B Specifications
Weights and Measures
| 23B | |
|---|---|
| Exterior Length | 24’6″ |
| Exterior Height | 10’11” |
| Exterior Width | 7’2.5″ |
| Exterior Storage (cu. ft.) | 64 |
| Awning Length | 13′ |
| Interior Height | 6’8″ |
| Interior Width | 6’9″ |
| Freshwater Tank Capacity (gal.) | 50 |
| Water Heater Capacity (gal.) | Continuous |
| Holding Tank Capacity — Black (gal.) | NA |
| Holding Tank Capacity — Gray (gal.) | 51 |
| LP Capacity (lbs.) | 40 |
| Fuel Capacity (gal.) | 24.5 |
| GCWR (lbs.) | 15,250 |
| GVWR (lbs.) | 11,030 |
| GAWR – Front (lbs.) | 4,410 |
| GAWR – Rear (lbs.) | 7,720 |
| Wheelbase | 170″ |
| Cassette Toilet Capacity (gal.) | 5 |
| Sleeps | 5 |
Chassis
- Mercedes-Benz® AWD Sprinter Chassis
- 2.0L high-output, turbo-diesel 4-cylinder engine, 9-speed automatic transmission with overdrive
- 4-wheel ABS brakes
- LED high performance headlamps
- Trailer hitch 5,000-lb drawbar/500-lb. Maximum vertical tongue weight w/7-pin connector
- All-terrain tires
- Stylized performance wheels
- Spare tire
Cab Conveniences
- MBUX® touchscreen multimedia infotainment system w/navigation, Wi-Fi hotspot, SiriusXM® capability, Apple CarPlay,® Android Auto™, Bluetooth®, intelligent voice control and rear camera
- Mercedes me connect app
- Leatherette cab seats w/memory control and power lumbar support, heated, and manual swivel
- 3-point seat belts
- Airbags driver and passenger
- Power assist steering w/tilt and telescoping wheel
- Digital rearview mirror
- Active braking assist
- Lane keeping assist
- Attention assist
- Traffic sign assist
- Automatic rain-sensing wipers
- DISTRONIC PLUS® (adaptive cruise control)
- Power mirrors w/defrost and turn signals
- Auto headlamps w/high beam assist
- Automatic climate control
- Power door locks w/remote
- Power windows
- Dash charging station w/wireless charging, 12V and USB powerpoints
- Sunvisors
- Thermal cab window blinds
- Thermal cab divider wall panel
Interior
- LED ceiling lights
- Tinted dual-pane euro acrylic windows w/screen and cassette shade
- Forward facing lounge w/3-point seat belts
- Pull-up/fold down table
- Removable pedestal table
- Side facing fixed sofa w/lap belt
- Color touchscreen systems monitor panel
- Vinyl flooring throughout
- Satellite system ready
- Amplified digital HDTV antenna
- Roof wiring access port
- Assist bar
- 110V, 12V, USB charging ports
- Deluxe powered ventilator fan w/remote
- Accent lighting
Optional Equipment:
- Entertainment system w/Bluetooth® soundbar and 24″ HDTV
- Front cab air mattress 30″ x 65″ w/support base, cordless pump, repair kit and storage bag
Galley
- Laminate countertops
- Microwave oven w/touch control
- Pantry
- 2-burner LP range cooktop w/cover
- 5.3 cu. ft. single door 12V refrigerator/freezer
- Stainless steel sink w/cover
- Adjustable/removable table/counter extension/workstation
Bath
- Medicine cabinet
- Oxygenics® shower head
- Dry/wet bath w/pivoting wall
- Robe hook(s)
- 24″x30″ Shower w/wall surround
- Shower curtain
- Molded round sink w/single control faucet
- Tissue holder
- Swiveling cassette toilet
Bedroom
- Twin beds w/WinnSleep™ System
- Flex bed kit
- Wardrobe/drawer storage below beds
- Metal clothes rod
- Room divider curtain
- Reading lights
- 110V, 12V, USB charging ports
Exterior
- Heated gear garage w/L-track cargo tie down system, 110V/12V charging ports and LED lighting
- Aluminum cab steps w/logoed tread and loop attachment
- Powered patio awning w/LED lighting and Bluetooth® control
- Ladder
- LED porch light w/interior switch
- Mud flaps
Optional Equipment:
- Pop-top sleeping area w/FROLI® sleep system and 110V/USB charging ports (N/A w/luggage rack or exterior kitchen)
- Batwing awning
- Luggage rack (N/A w/pop-top)
- Exterior kitchen w/chest style 12V refrigerator/freezer, 2-burner LP cooktop, flip-up counter extension, quick-connect faucet, collapsible sink, and LP quick-connect hose (N/A w/pop-top)
- Option to remove: Powered patio awning w/LED lighting and Bluetooth control
- Option to remove: Exterior graphics
Heating & Cooling
- 13,500 BTU air conditioner
- Truma® VarioHeat™ comfort
Electrical System
- Auxiliary start circuit
- Automatic dual-battery charge control
- Coach battery disconnect system
- Dedicated second alternator to charge coach batteries
- Exterior AC duplex receptacle
- Exterior TV jack
- Cummins Onan® QG 2800i gas generator
- 30-amp power cord
- (1) 320-amp-hour lithium ion battery w/Bluetooth control package and battery pack heating system
- (2) 170-watt and (1) 115-watt solar panel/battery charger
- 2,000-watt pure sine wave inverter/80-amp charger
Optional Equipment:
- Option to remove: Cummins Onan QG 2,800i gas generator
- Add (1) additional 320-amp-hour lithium ion battery (Generator delete mandatory with this option)
Plumbing
- Insulated water service center houses water center control panel, hooks, cable tv input, freshwater drain and portable satellite dish hook-up
- Truma AquaGo® tankless comfort plus water heater w/recirculation pump
- On-demand water pump
- Cold water purification system (galley only)
- Heated holding tank compartment
- 10′ sewer hose
- Shower drain pump
- LPG accessory connection (patio area)
Safety
- LPG leak, smoke and carbon monoxide detectors
- Fire extinguisher
- Ground fault interrupter
- Upper and lower child seat tether anchors (dinette seating)
- High-mount brake lamps
- Fog lamps
Warranty
-
12-month/15,000-limited warranty
-
36-month/36,000-mile limited warranty
-
10-year limited parts-and-labor warranty on roof skin
Specifications are subject to change without notification.
Featured Video
DECOR
Veredis
Juniper
