WEIGHTS & MEASURES
| 59P | 59PX | ||
|---|---|---|---|
| Exterior Length | 19’9″ | 21′ | |
| Exterior Height | 8’11″ | 9’5″ | |
| Exterior Width | 6’8″ | 6’8″ | |
| Interior Height | 6’2″ | 6’2″ | |
| Interior Width | 6’4″ | 6’4″ | |
| Freshwater Tank Capacity (gal.) | 21 | 21 | |
| Water Heater Capacity (gal.) | 2.6 | 2.6 | |
| Holding Tank Capacity – Gray | 20 | 20 | |
| LP Capacity (gal.) | 24.96 | 24.96 | |
| Fuel Capacity (gal.) | 24 | 24 | |
| GCWR (lbs.) | 11,500 | 11,500 | |
| GVWR (lbs.) | 8,900 | 9,350 | |
| GAWR – Front (lbs.) | 4,629 | 4,629 | |
| GAWR – Rear (lbs.) | 5,291 | 5,291 | |
| Wheelbase | 159″ | 159″ | |
| Cassette Toilet Capacity (gal.) | 5 | 5 | |
| Sleeps | 4 | 4 | |
CHASSIS
Ram ProMaster® 280-hp, 3.6L V6 gas engine, 6-speed automatic 62TE transmission, 180-amp. alternator 4-wheel ABS brakes Trailer Hitch6 3,500-lb. drawbar/350-lb. maximum vertical tongue weight 4-pin wiring connector
CAB CONVENIENCES
Radio/Rearview Monitor System 5″ LCD color touch screen, steering wheel controls, color rear camera, USB ports Cab seats adjustable headrest, slide/swivel/recline, and driver’s side right armrest Airbags driver and passenger Cruise control 3-point seat belts Power assist steering Manual adjust mirrors Power door locks w/remote Power windows 12-volt powerpoints Sunvisors Front and cab window privacy panels
INTERIOR
LED ceiling lights Tinted coach windows Systems monitor panel Roof vent (lounge) Removable pedestal table Below floor storage (lounge, bedroom) Reading lights Roof wiring access port Dinette seating w/3-point seat belts USB charging ports Zipped window coverings Heavy duty vinyl flooring throughout Ladder
GALLEY
Laminate countertop Pull-out countertop extension 2-burner range top w/glass cover Single door compressor-driven refrigerator/freezer 12-volt Stainless steel sink Spice Rack
BATH
Flexible showerhead Mirror Removable clothes rod Swiveling cassette toilet Shower curtain Shower w/wall surround Tissue holder
BEDROOM
Murphy+ bed w/access to storage below and mattress cover Deluxe powered ventilator fan Slat bed system Movable table Optional Equipment: Sofa/bed w/two 3-point seat belts
EXTERIOR
Pop-top sleeping area w/FROLI® sleep system Porch light w/interior switch Driver and passenger side service light Assist bar Side screen door Rear screen door Aluminum running board w/logoed tread and pet loop attachment Rod and privacy screen (provided for rear annex)
HEATING & COOLING SYSTEM
Truma Combi® Eco Heating System
ELECTRICAL SYSTEM
AC/DC load center, 45-amp. converter/charger Auxiliary start circuit 2 deep-cycle Group 31 batteries (AGM maintenance-free) Coach battery disconnect system Automatic dual-battery charge control 30-amp. power cord 220-watt flexible surface solar panel w/controller
PLUMBING SYSTEM
Exterior wash station (located behind passenger seat) 10′ sewer hose On-demand water pump Permanent-mount LP tank w/gauge Fresh water sight glass Heated drainage system Water center control panel includes all control valves, connection points and exterior wash station (located inside right rear door) Eco-Hot™ water system
SAFETY
LP, smoke, and carbon monoxide detectors 10 BC fire extinguisher Ground fault interrupter
WARRANTY
12-month/24,000-mile basic warranty
